Gansu Yinchuan International Cultural Exchange Center | Aluminum Frame Movable Partition Wall with High Pressure Laminate Board and Dupont POM Rollers for Top and Bottom Jack Lifting

Marka Adı:	AE
Model Numarası:	AE100
Moq:	10 metrekarelik
fiyat:	USD 90-125 Per Square Meter
Ödeme Şartları:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Tedarik Yeteneği:	Ayda 1000 metrekare

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Guangdong, Çin

Sertifika:

ISO9001 SGS

Model:

Hareketli Bölme Duvar

Panel:

Kumaşlı yanmaz levha

Uygunluk:

Ofis Binası, Okul

Kalınlık:

105cm

STC Derecelendirmesi:

42-56dB

Boyutlar:

Özelleştirme (Yükseklik: 18M'ye kadar, Panel başına Genişlik: 1,2M'ye kadar)

Ambalaj bilgileri:

Kontrplak kasası veya çelik paletli köpük tabakası ve sert karton

Vurgulamak:

800N Sealing Power Movable Partition Wall

40N/m Magnetic Attraction Operable Wall Panel

STC Rating 42-56dB Room Divider

Ürün Tanımı

Modern Auditorium Movable Partition Wall Hall Floor To Ceiling Soundproof

Movable partition boards offer a versatile and flexible solution for dividing spaces. Unlike traditional partitions with sliding teeth and push-pull rails, these boards can be easily attached or removed, featuring upper and lower centers designed for enhanced stability during assembly and disassembly.

These partitions consist of multiple panels that can be configured to open or close based on practical needs, providing a convenient and responsive way to manage space. Their primary function is to segment indoor areas into two or more distinct spaces, using a variety of decorative materials to achieve separation.

Movable partition boards are designed to maintain proper ventilation and lighting while being lightweight and slim. They combine ease of removal with necessary rigidity and sound insulation, making them suitable for dynamic and adaptable interior layouts.

The use of movable partition boards has expanded rapidly in recent years, offering a modern alternative to traditional fixed partitions and wet construction methods. Their easy installation process accelerates construction and preserves the overall aesthetic effect of the space.

Customizable to meet specific requirements, movable partition boards can be tailored in terms of model, surface finish, and storage options to match various design styles and site needs.

High-Quality Service Commitment

Our products are certified by SGS and ILAC-MRA, ensuring reliable performance.
We combine leading German partition technology to provide global professional space solutions.
Extend the lifespan of your professional products, ensuring long-term performance stability.
Provide quick follow-up and transparent quoting services to meet your needs.
Offer on-site inspection services to ensure quality and accuracy during project implementation.
We promise punctual delivery to ensure smooth project progress according to schedule.

Unique Roller Options & Features

Utilizes Dupont POM rollers for optimal performance.
Crafted from 304 stainless steel with heavy-duty capabilities, incorporating safety features and precision CNC machining.
Patented wheel design ensures effortless operation of the entire movable partition system.

Panel Options & Features

Thickness: 100mm for enhanced stability and sound insulation.
Offers a diverse range of acoustical and decorative finishes to suit various design preferences.
Constructed with a robust 6061-T6 profile and a Q235 steel frame inside for exceptional durability.
Features top and bottom jack lifting mechanisms with a sealing power of 800N. The magnetic seal with concave and convex profiles provides a magnetic attraction of 40N/m, ensuring secure closure and acoustic insulation.

Specification

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	65	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	85	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m

* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
